Easily add additional serial ports to your system. The Multi-8C/PCIe is equipped with SystemBase’s powerful semiconductors to deliver maximum performance up to 921.6Kbps with the world’s leading 256 byte FIFO preventing overrun errors. Combine that with the need for
fewer components and you get cost-effective and reliable connections to your serial devices. The Multiport boards support most Windows operating systems and include 15,000 volt surge suppression eliminating blown ports. The Multi-8C/PCIe includes a fan-out cable with DB9 connectors and is available in two models, RS232 and RS422/RS485(Combo). These boards are ideal for POS, hospitality, factory automation and building automation applications.
The SB16C1058PCI controller has a built-in 256-byte transmit/receive FIFO and various serial communication functions, reducing the need for additional components and improving circuit reliability. It also provides built-in protection against ±15KV surge electrical signals, supporting a stable communication environment even in industrial sites.
| Specification | PCI Express Base Specification Rev 2.0 |
| Interface | RS422 / RS485(COMBO) |
| Number of Communication Ports | 8 |
| Maximum Communication Speed | Up to 921.6Kbps |
| Signal Lines | RS422: TXD+, TXD-, RXD+, RXD- RS485: TRXD+, TRXD- |
| Data Bits | 5, 6, 7, 8 |
| Stop Bits | 1, 2 |
| Parity | None, Even, Odd |
| Protection | Built-in protection against ±15KV surge electrical signals |
| Communication Signal Collision Prevention | Auto toggling control by hardware or software |
| PCI Bus Controller | SB16C1058PCI |
| Cable Connector | DB9 Male |
| Cable Length | 320mm |
| Operating System | Windows 8 or later Windows Server 2012 or later Linux support |
| Utility | TestView |
| Operating Temperature | 0℃ to 50℃ |
| Storage Temperature | -20℃ to 80℃ |
| Humidity | 5 to 95% non-condensing |
| Certifications | CE, FCC, KC |
Click the button below to go to the resource center, where you can download related materials such as manuals, drivers, and utilities.
